• High volume fan provides cool air to the motor and pump
• Vapor discharge/oil fill port, easily removable, contains internal check valve to prevent escape of liquid oil
• Internal check valve to prevent oil back flow
• Cooling fins to keep temperature cooler during extended motor operation
• Thermally protected motor with on/off rocker switch
• Large, lightweight reinforced base for stable positioning
• Easily accessible oil drain valve
• Large oil level sight glass with max/min oil level indicator

SPECIFICATIONS:

• No. of Stages: 1
• Free Air Displacement: 3 CFM
• Ultimate Vacuum: 80 Microns
• Pump Motor: 1/4 HP
• Pump Speed: 1720 RPM
• Electrical Specs: 110/120 V/60 Hz
• Dimensions: 12 x 6 x 10.5″
• Shipping Weight: 14 lbs

* PLEASE NOTE: The micron readings on all vacuum pumps represent optimal laboratory conditions. Field conditions may vary from these readings.
