Perform pre-trip, post-trip and preventative maintenance inspections with the Pre-Trip Inspection Tool.
A 4-in-1 tool that allows drivers and technicians to visually inspect tire tread depth, brake stroke, brake shoe thickness and windscreen damage. When not in use, the Pre-Trip Inspection tool can easily fit in a pocket or on a keychain.

Preforms the following inspections:

• Brake Stroke
• Tire Tread Depth
• Windscreen cracks
• Brake pad thickness

Dimensions

A. 5/32” Steer tire depth
B. 3/32” drive and trailer tire tread depth
C. ¾” maximum size of windscreen chips
D. 9/32” brake shoe thickness
E. 2” maximum stroke for short stroke chamber
F. 2.5” maximum stroke for long stroke chamber
G. Keychain hole
*Note: Measurements for A, B & D are set 1/32” greater than the legal requirements to allow driver to take corrective action before the vehicle is out of compliance.
Manufactured in the USA
